24 LED MONITOR (24B30HM)-AOC

Brand
Name of the company-manufacturer.

AOC
Model
Designation of the model.

24B30HM
Model year
The year in which this model was announced.

2023
Display
Information about the main characteristics of the display – panel, backlight, resolution, refresh rate, etc.
Size class
Size class of the display as declared by the manufacturer. Often this is the rounded value of the actual size of the diagonal in inches.

23.8 in (inches)
Diagonal
Approximate diagonal size of the display. If the manufacturer does not provide such information, the diagonal is calculated from the width and height of the screen.

604.698 mm (millimeters)
60.4698 cm (centimeters)
23.807 in (inches)
1.9839 ft (feet)
Width
Approximate width of the display. If the manufacturer does not provide such information, the width is calculated from the diagonal and the aspect ratio.

527.04 mm (millimeters)
52.704 cm (centimeters)
20.7496 in (inches)
1.7291 ft (feet)
Height
Approximate height of the display. If the manufacturer does not provide such information, the height is calculated from the diagonal and the aspect ratio.

296.46 mm (millimeters)
29.646 cm (centimeters)
11.6717 in (inches)
0.9726 ft (feet)
Panel type
There are various panel technologies. Each has its own specific features – viewing angles, color reproduction, response time, brightness/contrast, production cost, etc. The image quality depends directly on the type of the display panel used.

VA
Panel bit depth
The most widely used panels are those with 6, 8, and 10 bits for each of the RGB components of the pixel. They provide 18-, 24-, and 30-bit color, respectively.

8 bits (6 bits + FRC)
FRC
Frame Rate Control (FRC) is a method, which allows the pixels to show more color tones. With quick cyclic switching between different color tones, an illusion for a new intermediate color tone is created. For example, by using FRC, a 6-bit display panel is able to show 16.7 millioin colors, which are typical for 8-bit display panels, and not the standard 262200 colors, instead. There are different FRC algorithms.

Yes
Colors
The maximum number of colors, which the display is able to reproduce, depends on the type of the panel in use and color enhancing technologies like FRC.

16777216 colors
24 bits
Aspect ratio
The ratio between the horizontal and the vertical side of the display. Some of the standard and widely used aspect ratios are 4:3, 5:4, 16:9 and 16:10.

1.778:1
16:9
Resolution
Information about the number of pixels on the horizontal and vertical side of the screen. A higher resolution allows the display of a more detailed and of higher quality image.

1920 x 1080 pixels
Full HD / 1080p
Pixel pitch
The pixel pitch shows the distance from the centers of two neighboring pixels. In displays, which have a native resolution (the TFT ones, for example), the pixel pitch depends on the resolution and the size of the screen.

0.275 mm (millimeters)
0.0275 cm (centimeters)
0.0108 in (inches)
0.0009 ft (feet)
Pixel density
Information of the number of pixels in a unit of length. With the decrease of the display size and the increase of its resolution, the pixel density increases.

92 ppi (pixels per inch)
36 ppcm (pixels per centimeter)
Display area
The percentage of the approximate area, taken by the active part of the screen, to the total front area.

89.98 % (percent)
Backlight
The backlight is the source of light of the LCD display panels. The type of backlight determines the image quality and the color space of the display. There are various backlights such as CCFL, LED, WLED, RGB-LED, and etc.

W-LED
sRGB
sRGB is a color space, developed jointly by Hewlett-Packard and Microsoft in 1996. It is used in different devices such as printers, displays, TV sets, cameras, etc. The sRGB color space covers about 72% of the NTSC color space.

100 % (percent)
NTSC (1953)
The NTSC (1953) color space is introduced in 1953 by the FCC with the appearance of color television and has a wider gamut than the sRGB.

84 % (percent)
DCI P3
DCI P3 is a color space, introduced in 2007 by the SMPTE. It is used in digital cinema and has a much wider gamut than the sRGB.

93 % (percent)
Brightness
Information about the brightness of the screen. It is measured in candela per square metre (cd/m²).

250 cd/m² (candela per square meter)
Static contrast
The static contrast shows the ratio between the brightest and the darkest color, which the display can reproduce simultaneously, for example, within one and the same frame/scene.

4000 : 1

Camera
Information whether the current model has a built-in camera or not.

No
Connectivity
Available connectivity ports, slots and interfaces.
Connectivity
Information about the available connectivity ports, slots and interfaces such as USB, infrared port, SD card slot, audio/video and network interfaces, etc.

1 x HDMI 1.4
1 x D-sub
High-bandwidth Digital Content Protection (HDCP)
Features
Some additional functional features of the model.
Features
Information about additional software features, technologies, functions and services of the model.

Clear Vision
Dynamic Colour Boost (DCB) technology
Dynamic Contrast Ratio (DCR) technology
Flicker-free technology
HDR Mode
Low Blue Light
Certificates, standards and licenses
Licenses from regulatory agencies, standards, certificates.
Certificates, standards and licenses
List of the standards, certificates and licenses supported/received by the current model.

CCC
CE
CECP
CEL
CH RoHS
FCC
Win11
Accessories
Often the packaging of desktop monitors and smart TV sets includes accessories for them.
Accessories
Information about some of the main accessories included in the standard packaging of the current model.

HDMI cable
